4/6/10mm² Solar PV Connector with Bimetal Pin

البيانات الفنية

Insulation material

PPE PA66

Rated current

40A

Rated voltage

1500V

Test voltage

8kV(50Hz,1min)

Contact resistance

<0.5mΩ

Contact material

Copper, Aluminium, rod

Degree of protection

IP2X/IP67

Safety class

II

Flame class

UL94-V0

Insertion force

Max.50N

Withdrawal force

Min.50N

Ambient temperature range

-40C...+85C
